Port Mills

SCT Port Mills machine SAE J1926 ORB and AS5202 hydraulic port profiles using circular or helical interpolation from a pre-drilled hole. Available uncoated or with Versa (AlCrN).

Port Mill vs. Port Contour Cutters

One Port Mill can cover a range of port sizes, reducing the need to stock a dedicated porting tool for every individual size.

Manufactured by Scientific Cutting Tools



AS5202

  • Machines AS5202 port profiles using circular interpolation

  • Generates the seal surface, counterbore, and chamfers

  • Improves access in tight spaces and restricted setups

  • Covers multiple port sizes with one tool

  • Available uncoated or with Versa (AlCrN) coating

AS5202 Port Mills are solid carbide milling tools designed to generate AS5202 hydraulic port profiles through circular interpolation from a pre-drilled hole. Each tool covers a range of port sizes, making the series a flexible option for prototypes, small batches, and applications that are difficult to reach with traditional porting tools.

AS5202 Technical Details
E Q D A S OAL Uncoated Tool # Uncoated EDP # Versa (AlCrN) EDP #
0.071 0.035 0.230 0.118 0.250 2.50 AS5202M2-3 SCI.408050 SCI.408056
0.083 0.035 0.265 0.118 0.312 2.50 AS5202M4-5 SCI.408051 SCI.408057
0.091 0.035 0.335 0.126 0.375 3.00 AS5202M6 SCI.408052 SCI.408058
0.102 0.040 0.413 0.142 0.500 3.50 AS5202M7-8 SCI.408053 SCI.408059
0.133 0.040 0.461 0.173 0.500 3.50 AS5202M10 SCI.408054 SCI.408060
0.133 0.045 0.681 0.178 0.750 4.00 AS5202M12-32 SCI.408055 SCI.408061





Back to Top of Page






SAE J1926 Port Mills



  • Machines SAE J1926 ORB port profiles using circular interpolation

  • Generates the seal surface and chamfers

  • Improves access in tight spaces and restricted setups

  • Covers multiple port sizes with one tool

  • Available uncoated or with Versa (AlCrN) coating

SAE J1926 Port Mills are solid carbide milling tools designed to generate O-Ring Boss hydraulic port profiles through circular interpolation from a pre-drilled hole. Each tool covers a range of port sizes, making the series a flexible option for prototypes, small batches, and applications where traditional traditional port tools are difficult to reach.

SAEJ 1926 Technical Drawing
K E Q D A S OAL Uncoated Tool # Uncoated EDP # Versa (AlCrN) EDP #
12° 0.087 0.033 0.220 0.120 0.250 2.50 SAEJ1926M2-3 SCI.408000 SCI.408004
12° 0.104 0.046 0.335 0.150 0.375 3.00 SAEJ1926M4-6 SCI.408001 SCI.408005
15° 0.108 0.052 0.460 0.160 0.500 3.50 SAEJ1926M8-10 SCI.408002 SCI.408006
15° 0.138 0.052 0.710 0.190 0.750 4.00 SAEJ1926M12-32 SCI.408003 SCI.408007





Back to Top of Page



Product Comparison: Port Mills vs. Traditional Porting Tools

Traditional porting tools are an effective choice for many dedicated production applications.

Port Mills add flexibility when the job calls for more access, smaller machine compatibility, or broader size coverage.

  • Hard-to reach port locations
  • Angled faces or tight spaces
  • Smaller or lower-RPM equipment
  • Prototypes, repairs, and small batches
Back to Top of Page



Versa (AlCrN) Coating

  • Best for: Steels, stainless steels, tool steels, titanium, high-temp alloys, cast iron
  • Choose it when: Heat and wear are the primary challenges.
  • Helps with: Heat resistance, wear protection, and stable cutting performance
Back to Top of Page
